Monel Ball Valve

Home > Monel > Monel Ball Valve

At Mirza Tubefittings in Safat, Kuwait, we proudly manufacture and supply high-performance Monel Ball Valves designed to withstand the most demanding industrial environments. Known for its outstanding resistance to corrosion, especially in marine and chemical processing conditions, Monel brings reliability to systems where ordinary materials fail. Our valves are crafted with precision, ensuring smooth operation, leak-free performance, and impressive longevity. Whether it’s offshore platforms, desalination plants, or chemical lines, customers trust us for quality that feels dependable and built to last. With a focus on durability and user-centric design, Mirza Tubefittings delivers valves that make operations safer and more efficient.

Monel Instrumentation Ball Valve Manufacturer in Safat, Monel Alloy Compression Ball Valve in Salmiya, Monel Hydraulic Ball Valve Supplier in Hawalli, Monel High Pressure Ball Valve Price List in Safat, Monel 2 Way Ball Valve Price in Salmiya, Monel Alloy 3 Way Ball Valve in Safat, Kuwait, Monel 4 Way Ball Valve Price in Jahra, Monel 5 Way Ball Valve Supplier in Hawalli, Monel High Pressure Ball Valve Price List in Al Ahmadi

Monel Ball Valves are produced using high-nickel Monel alloys, typically containing around 63% nickel and 30–34% copper, along with trace elements such as iron, manganese, and silicon. This composition offers superior resistance to seawater, acids, and alkalis. Mechanically, Monel alloys provide excellent tensile strength, impressive ductility, and stability across extreme temperatures. The valves exhibit low corrosion fatigue and strong impact resistance, making them ideal for harsh operating conditions. Their metallurgical stability helps maintain consistent performance in high-pressure and high-salinity environments.

Monel Ball Valve Specifications

STANDARD	ASTM A494 / ASME SA494 API 600/BS1414, ASME B 16.34, ASME B 16.10, ASME B 16.5, API 598/BS EN 12266-1,ASME B 16.25
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Monel Ball Valve Chemical Composition

Material	C	Mn	Si	S	Cu	Fe	Ni	Cr
Monel	0.30 max	2.00 max	0.50 max	0.24max	28.0-34.0	2.50 max	63.00 min	–

Monel Ball Valve Mechanical Properties

Element	Yield Strength (0.2%Offset)	Melting Point	Density	Elongation	Tensile Strength
Monel	Psi – 35,000 , MPa – 240	1350 °C (2460 °F)	8.8 g/cm3	40 %	Psi – 80,000 , MPa – 550

Monel Ball Valve Equivalent

STANDARD

WNR Material Number

UNS

JIS

GOST

AFNOR

Monel 400

2.4360

N04400

NW 4400

NA 13

МНЖМц 28-2,5-1,5

NU-30M

NiCu30Fe

Top Monel Ball Valve Manufacturing Company in Safat

At Mirza Tube Fittings, we are the largest supplier, manufacturer, and exporter of Monel Ball Valve in Safat, Kuwait. Our advanced manufacturing facilities, strategically positioned in the Kuwait, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Monel Ball Valve

Monel Alloy High Pressure Ball Valve in Salmiya, Monel 2 Way Ball Valve Supplier in Hawalli, Monel 3 Way Ball Valve in Safat, Kuwait, Monel Alloy 3 Way Ball Valve Price List in Safat, Monel 5 Way Ball Valve Price in Salmiya, Monel Instrumentation Ball Valve Price in Jahra, Monel Compression Ball Valve Supplier in Hawalli, Monel Hydraulic Ball Valve Manufacturer in Safat

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Monel Ball Valve in Safat, Kuwait

Mirza Tube Fittings is a leading supplier and stockist of premium Monel Ball Valve in Safat, Kuwait. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Monel Ball Valves Uses

Monel Ball Valves are widely used in industries where corrosion poses significant challenges. They play an essential role in marine engineering, such as seawater piping, ship systems, and offshore platforms. In chemical and petrochemical plants, they manage aggressive acids, saline solutions, and harsh chemicals with ease. Their dependability makes them suitable for oil & gas processing, desalination plants, power generation units, and even aerospace components where strength and corrosion resistance are critical. Thanks to their durability and low maintenance needs, Monel Ball Valves are trusted for long-term service in applications where safety and reliability cannot be compromised.
