Stainless Steel 316 Ball Valve

Home > Stainless Steel >Stainless Steel 316 Ball Valve

Mirza Tubefittings stands out as a top-notch manufacturer and supplier of Stainless Steel 316 Ball Valves in Safat, Kuwait. Renowned for their precision engineering and robust construction, these valves are designed to handle high pressures, corrosive fluids, and tough industrial settings. Each 316 ball valve adheres to international standards, guaranteeing leak-free performance, reliability, and a long lifespan. Thanks to advanced manufacturing techniques and expert knowledge, Mirza Tubefittings delivers solutions perfect for chemical, petrochemical, oil and gas, marine, and industrial hydraulic systems that demand strong and accurate flow control.

Stainless Steel 316 One-Piece Instrumentation Ball Valves Manufacturer in Safat, Stainless Steel DIN 1.4436 Compression Ball Valve in Salmiya, SS UNS S31600 Hydraulic Ball Valve Supplier in Hawalli, X5CrNi18-10 Stainless Steel High Pressure Ball Valve Price List in Safat, 316 Stainless Steel 2 Way Ball Valve Price in Salmiya, DIN 1.4436 SS 3 Way Ball Valve in Safat, Kuwait, UNS S31600 Stainless Steel 4 Way Ball Valve Price in Jahra, 316 Stainless Steel 5 Way Ball Valve Supplier in Hawalli

Crafted from austenitic stainless steel, these ball valves contain about 16–18% chromium, 10–14% nickel, and 2–3% molybdenum. This unique blend offers outstanding resistance to corrosion, pitting, and crevice attack, even in environments rich in chlorides. On a mechanical level, 316 stainless steel boasts high tensile strength, toughness, and ductility, making it ideal for high-pressure situations and extended use in challenging conditions.

Stainless Steel 316 Ball Valve Specifications

VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
BRAND NAME	TU-LOK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
EQUIVALENT BRANDS	SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Stainless Steel 316 Ball Valve Chemical Composition

Grade		Mn	C	S	Mo	N	Si	P	Cr	Ni
316	Minimum	–	–	–	2.00	–	–	0	16.0	10.0
316	Maximum	2.0	0.08	0.03	3.00	0.10	0.75	0.045	18.0	14.0
316H	Minimum	0.04	0.04	–	2.00	–	0	–	16.0	10.0
316H	Maximum	0.10	0.10	0.03	3.00	–	0.75	0.045	18.0	14.0

Stainless Steel 316 Ball Valve Mechanical Properties

Grade	Yield Strength	Tensile Strength	Elongation (%)	Reduction of Area (%)	Hardness Max
Grade	Min (Mpa)	Min (Mpa)	Min	Min (50mm)	HB
Stainless Steel 316 Valves	170	485	30	50	217*
Stainless Steel 316 Valves	205	515	30	50	217*

Stainless Steel 316 Ball Valve Equivalent

Grade	British		Euronorm		UNS No	SS	JIS
Grade	European Standards	British Standards	DIN No	Name	UNS No	SS	JIS
316	58H, 58J	316S31	1.4401	X5CrNiMo17-12-2	S31600	2347	SUS 316
316H	–	316S51	–	–	S31609	–	–

Top Stainless Steel 316 Ball Valve Manufacturing Company in Safat

At Mirza Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel 316 Ball Valve in Safat, Kuwait. Our advanced manufacturing facilities, strategically positioned in the Kuwait, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel 316 Ball Valve

Stainless Steel 316 Instrumentation Ball Valve Price in Jahra, UNS S31600 Stainless Steel Compression Ball Valve Supplier in Hawalli, X5CrNi18-10 Stainless Steel Hydraulic Ball Valve Manufacturer in Safat, DIN 1.4436 Stainless Steel High Pressure Ball Valve in Salmiya, 316 Stainless Steel 2 Way Ball Valve Supplier in Hawalli, UNS S31600 Stainless Steel 3 Way Ball Valve in Safat, Kuwait, DIN 1.4436 Stainless Steel 3 Way Ball Valve Price List in Safat, 316 SS 5 Way Ball Valve Price in Salmiya

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 316 Ball Valve in Safat, Kuwait

Mirza Tube Fittings is a leading supplier and stockist of premium Stainless Steel 316 Ball Valve in Safat, Kuwait. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 316 Ball Valves Uses

These ball valves find their place in various sectors, including chemical processing, petrochemical, oil and gas, marine, and industrial hydraulic systems. They excel in providing leak-free operation, precise flow control, and resistance to aggressive fluids. With their reliable and efficient performance in critical industrial applications, Stainless Steel 316 Ball Valves are a trusted choice for even the most demanding environments.
